Features

  • Vann-BUS Battery Equalizer provides regulated 12V power from a dual-battery system, aligned in series, that is providing 24V
  • Vann-BUS ensures current is taken equally from both batteries
  • Vann-BUS ensures the voltage in both batteries remain equal
  • Vann-BUS is designed to be able to operate multiple units in parallel to provide more power capabilities
  • Protection against overcharging batteries
  • Advanced system monitoring technology through J-1939 CanBUS or integrated battery monitor
  • Internal Electronic Monitoring of critical function
  • Fault signaling to optional warning system of lights, buzzers, or other devices
  • Under voltage Protection
  • Equalizer Fault Output
  • Equalizer Ignition Input
  • Remote Sense
  • Monitor System Output with Deutsch connector
  • See Owner's Manual for typical product application diagrams and monitor functionality
  • 2-yr warranty
  • Complimentary products available from Havis: Battery Isolator, DC to AC Inverter, Battery Charger, DC Converter
  • Typical Installation Applications include: Transit Bus, Private Coach, Tour/Charter Coach, Heavy Truck, and Boats

PRODUCT SPECIFICATIONS:
IP Rating:IP56
DC Input:18-32 VDC
DC Voltage Range:50% of the Input Voltage (±2%)
Operating Temperature:-40F to 167F (-40C to +75C)
Efficiency:>97%
Standby Current:17 mA
Dimensions:10.6”H x 8.5”W x 3.6”D
Product Weight:9.3 lbs
Gross weight:10 lbs

Resources

Owner's Manual
Owner's Manual
